JSON

An introduction to JSON.

10 minute read

Updated:

Categories: ,

Context: This was written as accompanying material for the MDG Library Carpentry workshop 2026 in Birmingham. Check out the workshop page for a list of all covered topics.

JSON1 stands for JavaScript Object Notation (it was extended from JavaScript). It was developed 2000/2001 and first standardised in 2013 as ECMA-4042 and then again in 2017 as RFC 82593 and ISO-IEC 21778:20174.

Just like XML its purpose is data serialisation (i.e. data storage, transmission and reconstruction).

But, it’s a lot easier! No namespaces for starters😋

JSON Syntax

The basic premise is key-value pairs. You’ve seen this in action as attributes in XML: the attribute name is the key and the value, well, the value. Key and value are separated by :.

Keys must be strings in JSON, but values can have a number of different data types:

  • string values are enclosed in "" (" occurring in a string value must be escaped as \"),
  • number (there is no distinction between integer and float),
  • Boolean (true or false),
  • arrays are enclosed in [ ] and can consist of values of all data types in this list,
  • objects are enclosed in { } and consist of key-value pairs whose keys should be unique within the object, and
  • null, which means no value (slightly different from the key not existing at all)

The values in arrays and objects are separated by ,.

The root element must either be an object or an array.

There is no provision for comments in JSON.

That’s it. That’s all the rules.5

JSON example

Using our cats example, let’s start by describing an individual cat. We’ll need keys for id, name, age, breed and colour; they are already strings, so let’s just use them. And we need to wrap them in an object ({ }) as we need a root object or array.

{
    "id": 1,
    "name": "Duncan",
    "age": 10,
    "breed": "moggy",
    "colour": ["orange", "white"]
}

That’s it. Cat described.

To add another cat, let’s wrap our existing cat object in an array and add a second object describing a cat.

[
    {
        "id": 1,
        "name": "Duncan",
        "age": 10,
        "breed": "moggy",
        "colour": ["orange", "white"]
    },
    {
        "id": 2,
        "name": "Izzy",
        "age": 5,
        "breed": "moggy",
        "colour": ["black"]
    }
]

The only two data types that out example doesn’t cover yet are Boolean and null.

To demonstrate Boolean, let’s add the key “hungry” to each cat. Duncan is hungry and Izzy is not:

[
    {
        "id": 1,
        "name": "Duncan",
        "age": 10,
        "breed": "moggy",
        "colour": ["orange", "white"],
        "hungry": true
    },
    {
        "id": 2,
        "name": "Izzy",
        "age": 5,
        "breed": "moggy",
        "colour": ["black"],
        "hungry": false
    }
]

Finally, null: Say we don’t know the age of our cats. There are two options, we simply omit the key or we set its value to null.

[
    {
        "id": 1,
        "name": "Duncan",
        "breed": "moggy",
        "colour": ["orange", "white"],
        "hungry": true
    },
    {
        "id": 2,
        "name": "Izzy",
        "age": null,
        "breed": "moggy",
        "colour": ["black"],
        "hungry": false
    }
]

What’s the difference? You’ll mostly notice it when working with JSON data and extracting values from it. If a key doesn’t exist you might get an error, where as if it does and the value is null, you get the null value.

Validating JSON

The validation vocabulary for JSON is called JSON Schema6. JSON Schema documents are JSON documents. I have yet to encounter a situation where I had to work with this beyond experimentation, hence we’ll not dwell on it. I’ll just show you what it looks like and talk you through.

{
    "$schema": "https://json-schema.org/draft/2020-12/schema",
    "$id": "https://www.example.com/cats.json",
    "title": "Cats",
    "description": "Describe some cats",
    "type": "array",
    "properties": {
        "id": {
            "description": "The cat's ID",
            "type": "integer",
            "minimum": 1
        },
        "name": {
            "description": "The cat's name",
            "type": "string"
        },
        "age": {
            "description": "The cat's age",
            "type": "integer",
            "minimum": 0
        },
        "breed": {
            "description": "The cat's breed",
            "type": ["string", "null"]
        },
        "colour": {
            "description": "The cat's colour(s)",
            "type": "array",
            "items": {
                "enum":[
                    "black",
                    "white",
                    "orange",
                    "blue",
                    "cream",
                    "lilac",
                    "chocolate",
                    "cinnamon",
                    "fawn"
                ]
            }
        }
    },
    "required": [
        "id",
        "name"
    ],
    "additionalProperties": false
}
  • "$schema": "https://json-schema.org/draft/2020-12/schema" defines the version of JSON Schema this document uses.
  • "$id": "https://www.example.com" sets a unique identifier for the schema
  • "title" and "description" is metadata about the schema, i.e. giving it a title and saying something about its purpose etc.
  • "type": "array" means it expects an array as the root element
  • "properties": {...} describes the keys and which data format their values are and any other restrictions placed on them. The keys described are:
    • "id", whose value should be an integer with a minimum value of 1,
    • "name", whose value should be a string,
    • "age", whose value should be an integer with the minimum allowed value being 0,
    • "breed", whose value should be a string or null,
    • "colour", whose value should be an array whose value(s) should be black, white, orange, blue, cream, lilac, chocolate, cinnamon or fawn.
  • "required": ["id", "name" ] means that the keys id and name must be present, for each cat, all others are optional.
  • additionalProperties": false" means no keys other than the ones given are allowed.

XML vs JSON

If your use case doesn’t dictate which format to use, how do you decide? There are some significant differences between XML and JSON that usually make JSON the better and easier to work with choice, especially if you also work with the data programmatically.

  XML JSON
Syntax and readability Verbose and can be hard to read due to tag structure Compact and easier to read due to key-value pair syntax
File size Larger, due to verbosity Smaller
Parsing Needs a complex parser to read and write programmatically Is simpler and quicker to parse programmatically and maps easily into languages such as JavaScript and Python
Data type support More flexible and supports complex data types Limited range of data types
Ease of use More complex and less flexible Simple and flexible
Validation Can be validated using XML Schema Can be validated using JSON Schema
Security Has some security concerns re DTDs, don’t use them. Is safer than XML

This might make it sound like JSON is always the better choice, but that’s not true. If you need namespaces, data types JSON cannot support or very complex data structures, XML does the better job.7

Annotated bibliography and further reading

The technical standards:

JSON Schema:

The most recent version of JSON Schema is 2020-12. JSON Schema is not a recognised standard (yet?), hence the version thing.

To get started with JSON Schema I found these pages useful:

Other sources I used when putting the workshop together:

  1. The information in this section has been, unless stated otherwise, compiled using the following sources: Bray, Tim, 2017, ‘JavaScript JSON’, no date, ‘JSON’, 2026 ↩

  2. ECMA International, 2013 and the second edition ECMA International, 2017 ↩

  3. Bray, Tim, 2017 ↩

  4. International Organization for Standardization, 2017 ↩

  5. There are some intricacies of which characters can be used for numbers and encoding bits for strings. None of which are terribly relevant for bibliographic use cases. See Bray, Tim, 2017. ↩

  6. JSON Schema, no date ↩

  7. The information in this section has been, unless stated otherwise, compiled using the following sources: Amazon Web Services, no date, Liquid Technologies, 2025 ↩
